​Main Specification

X Axis Travel 700mm (27.56")
Y Axis Travel 850mm (33.46")
Z Axis Travel 610mm (24.02")
A Axis Travel -120 to +30 degrees
C Axis Travel 360 degrees
Spindle Speeds 20,000 min-1
Spindle Motor 30/25HP
Magazine Capacity 60
Table Size 500mm (19.69") Square
Spindle Taper No. 40
Controller Type FANUC31iB5
Max. Work Dia/Height 700mm (27.6") / 500mm (19.7")
Max. Weight Loadable on Table 500kg (1102 lbs)

OKK VCX-500 5 AXIS MACHINING CENTER

​

- 20,000 RPM BIG PLUS DUAL CONTACT SPINDLE

​

- 1000 PSI CHIP BLASTER THRU SPINDLE

  COOLANT UNIT

- BLUM TOOL SETTING UNIT​

​

- BLUM PART PROBING UNIT

​
